Product Description
●DESIGN FEATURES
★BEARINGsvSTEM:
SLEEVEBEARING&BALL BEARING
★IMPELLER:
PLASTIC WITH FIBER GLASS FILLED UL 94V-0
★HOUSING:
PLASTIC WITH FIBER GLASS FILLED UL94V-0
★cONECTING:
WIRE LEADS
★ALLoWABLE AMBIENT TEMPERATURE RANGE:
-10℃ ~+70℃(Operation)-40℃ ~+80℃(Storage)
●SPECIFICATIONS
| Listed Model | Bearing System | Rated Voltage (VDC) | Startup Voltage (VDC) | Current (A) | Speed (RPM) | Air Flow (CFM) | Static Pressure (mmH₂O) | Noise Level (dBA) | WeightG |
| TD122518M | Sleeve or ball | 18 | 6 | 0 15 | 1800 | 56 8 | 2.86 | 29.25 | 83 |
| TD122518H | Sleeve or ball | 18 | 6 | 0.22 | 2000 | 65.36 | 3.18 | 32.6 | 83 |
