DC/EC Motor

Product Description


★lnsuation:Class B
★Type of protection:lP42
★Mode of operation:S1
★Operation Temperature:-25--70℃
★Material:Sheet steel \Aluminum\Pa66
★Available Features:
·Tachilable Out put
·Slow startup
·Pulse wIDTH Modulation
·control input 0--10VDC
★EMC:Interference emission acc.to EN 61000-6-3
★lnterference immunily acc.to EN 61000-6-2
★Product conforming to standard: EN 60950-1


Model Bearing System Voltage v Voltage Range fAriallb0liolc0lp32;FREELOAD fAriallb0liolc0lp32;AT MAX EFFLCLENCY PAT MAX OUT POWER WeightG
Current (A) Speed (RPM) TORQUE(mN.m Speed (RPM) CurrentA OUTPUT(W) TORQUE(mN.m
TD533624HB-M Ball 24VDC 12-26.4 0.05 3180 22.4 2863 0.39 35 74.15 265
