Product Description
●DESIGN FEATURES
★BEARINGsvSTEM:
SLEEVEBEARING&BALL BEARING
★IMPELLER:
PLASTIC WITH FIBER GLASS FILLED UL 94V-0
★HOUSING:
PLASTIC WITH FIBER GLASS FILLED UL94V-0
★cONECTING:
WIRE LEADS
★ALLoWABLE AMBIENT TEMPERATURE RANGE:
-10℃ ~+70℃(Operation)-40℃ ~+80℃(Storage)
●SPECIFICATIONS
| Listed Model | Bearing System | Rated Voltage (VDC) | Startup Voltage (VDC) | Current (A) | Power W | Speed (RPM) | Noise(DBA) | Air Flow | Static Pressure | ||
| M³/H | CFM | Pa | mmH2O | ||||||||
| TD702812HB-K-GP | Ball | 12VDC | 9—13.2 | 0.17 | 1.68 | 3200 | 40 | 13.6 | 8 | 61.4 | 6.2 |
