Product Center

Page view:
Product name

TD6020-K

Numbering
TD6020-K
Affiliate classification
没有此类产品
Product description




★lnsuation:Class B
★Type of protection:lP42
★Mode of operation:S1
★Certification:UL/CUL/CE/CCC
★Operation Temperature:-25--70℃
★Material:Sheet steel \Aluminum\Pa66
★Available Features:
·Tachilable Out put
·Autorestart
·Slow startup
·Pulse wIDTH Modulation
·control input 0--5VDC
★EMC:Interference emission acc.to EN 61000-6-3
★lnterference immunily acc.to EN 61000-6-2
Product conforming to standard: EN 60950-1

●SPECIFICATIONS


Model Bearing System Voltage v Voltage Range Current A Power W Speed RPM Noise DBA Air Flow Static Pressure  Weight G
M³/H CFM Pa mmH2O
TD602005LS-K Sleeve 5VDC 4. 5-5. 5 0.28 1.40 3300 30.9 92 5.4 134.7 13.3 42
TD602012MS-K Sleeve 12VDC 9-13. 2 0.17 2.04 4000 43.3 11.2 6.6 146.6 14.5 42
TD602012HS-K Sleeve 12VDC 9-13. 2 0.34 4.08 5000 47 14 8.3 222.6 22.1 42
TD602012HS-K Sleeve 12VDC 9-13. 2 0.35 4.2 5200 49 14.6 8.6 231 23.0 42
TD602012HS-K Sleeve 12VDC 9-13. 2 0.36 4=32 5300 49.9 14.9 8.8 236.5 23.5 42
