Product name

TD 2510

Numbering
TD 2510
Affiliate classification
没有此类产品
Product description

●DESIGN FEATURES
★BEARING sYSTEM:
SLEEVE BEARING&BALL BEARING
★IMPELLER:
PLASTIC WITH FIBER GLASS FILLED UL 94V-o
★HOUSING:
PLASTIC WITH FIBER GLASS FILLED UL94v-oCONNECTING:
WIRE LEADS
★ALLOWABLE AMBIENT TEMPERATURE RANGE:-10℃ ~+70℃(operation)-40℃ ~+80℃(Storage)

●SPECIFICATIONS

Listed Model Bearing System Rated Voltage (VDC) Startup Voltage (VDC) Current (A) Speed (RPM) Air Flow (CFM) Static Pressure (mmH20) Noise Level (dBA) Weight (g)
TD251012L Sleeve or ball 12 6.0 0.05 9000 2.0 3.32 22.8 6.5
TD251012M Sleeve or ball 12 6.0 0.07 11000 2.5 4.96 27.2 6.5
TD251012H Sleeve or ball 12 6.0 0.09 13000 2.9 6.93 30.8 6.5
TD251005L Sleeve or ball 5 3.5 0.10 9000 2.0 3.32 22.8 6.5
TD251005M Sleeve or ball 5 3.5 0.16 11000 2.5 4.96 2.72 6.5
TD251005H Sleeve or ball 5 3.5 0.24 13000 2.9 6.93 30.8 6.5
