Product name

TD 4020

Numbering
TD 4020
没有此类产品
Product description




●DESIGN FEATURES
★BEARING sYSTEM:
SLEEVEBEARING&BALL BEARING
★IMPELLER:
PLASTIC wWITH FIBER GLASS FILLED UL 94V-o
★HOUSING:
PLASTICWITH FIBER GLASS FILLED UL94V-o
★CONNECTING:
WIRE LEADS
★ALLOWABLE AMBIENT TEMPERATURE RANGE:-10℃ ~+70℃(Operation) -40℃ ~+80℃(Storage)

●SPECIFICATIONS


Listed Model Bearing System Rated Voltage (VDC) Startup Voltage (VDC) Current (A) Speed (RPM) Air Flow (CFM) Static Pressure (mmH20) Noise Level (dBA) Weight (g)
TD402012L Sleeve or ball 12 6.0 0.09 6000 8.6 3.56 25.2 23.0
TD402012M Sleeve or ball 12 6.0 0.11 7000 10.0 4.85 28.5 23.0
TD402012H Sleeve or ball 12 6.0 0.13 8000 11.4 6.33 31.4 23.0
TD402012D Sleeve or ball 12 6.0 0.27 10000 14.3 7.91 34.3 23.0
TD402005L Sleeve or ball 5 3.5 0.18 6000 8.6 3.56 25.2 23.0
TD402005M Sleeve or ball 5 3.5 0.26 7000 10.0 4.85 28.5 23.0
TD402005H Sleeve or ball 5 3.5 0.35 8000 11.4 6.33 31.4 23.0
Corresponding parameter set not found, please add it in property template of background
