Product Description
●DESIGN FEATURES
★BEARING sYSTEM:
SLEEVE BEARING&BALL BEARING
★ IMPELLER:
PLASTICWITH FIBER GLASS FILLED UL 94V-o
★HoUSING:
PLASTIC WITH FIBER GLASS FILLED UL94V-o
★CONNECTING:
WIRELEADS
★ALLOWABLE AMBIENT TEMPERATURE RANGE:-10℃~+70℃(Operation)-40℃~+80℃(Storage)
●SPECIFICATIONS
| Model | Bearing System | Voltage v | Voltage Range | Current A | Power W | Speed RPM | Noise DBA | Air Flow | Static Pa | Pressure mmH2O | |
| M³/H | CFM | ||||||||||
| TD402812H | Ball | 12VDC | 6-13.2 | 0.92 | 11.04 | 22000 | 61 | 48.6 | 28.6 | 799 | 81.5 |
| TD402824H | Ball | 24VDC | 12-26.4 | 0.46 | 11.04 | 22000 | 61 | 48.6 | 28.6 | 799 | 81.5 |
