Product Description
●DESIGN FEATURES
★BEARING sYSTEM:
SLEEVE BEARING&BALL BEARING
★IMPELLER:
PLASTIC WITH FIBER GLASS FILLED UL94V-o
★HOUsING:
PLASTICWITH FIBER GLASS FILLED UL94V-o
★cONNECTING:
WIRELEADS
★ALLOWABLE AMBIENT TEMPERATURE RANGE:-10℃ ~+70℃(Operation) -40℃ ~+80℃(Storage)
●SPECIFICATIONS
| Model | Bearing System | Voltage v | Voltage Range | Current A | Power W | Speed RPM | Noise DBA | Air Flow | Static Pressure | ||
| M³/H | CFM | Pa | mmH2O | ||||||||
| TD923812H | Ball | 12VDC | 6-13.2 | 4.8 | 57.6 | 14900 | 72 | 306 | 180 | 1100 | 112.2 |
| TD923824H | Ball | 24VDC | 12-26.4 | 2.4 | 57.6 | 14900 | 72 | 306 | 180 | 1100 | 112.2 |
| TD923848H | Ball | 48VDC | 24-52.8 | 1.2 | 57.6 | 14900 | 72 | 306 | 180 | 1100 | 112.2 |
