Product name

TD 1225-3

Numbering
TD 1225-3
没有此类产品
Product description




●DESIGN FEATURES
★BEARING sYSTEM:
SLEEVE BEARING&BALL BEARING
★IMPELLER:
PLASTIC WITH FIBER GLASS FILLED UL94V-o
★HOUsING:
PLASTICWITH FIBER GLASS FILLED UL94V-o
★cONNECTING:
WIRELEADS
★ALLOWABLE AMBIENT TEMPERATURE RANGE:-10℃ ~+70℃(Operation) -40℃ ~+80℃(Storage)

●SPECIFICATIONS


Model Bearing System Voltage v Voltage Range Current A Power W Speed RPM Noise DBA Air Flow Static Pressure
M³/H CFM Pa mmH2O
TD122512L-3 Sleeve/Ball 12VDC 6—13.2 0.17 2.04 1700 24.24 110.16 64.8 30.67 3.13
TD122524H-3 Sleeve/Ball 24VDC 12—26.4 0.23 5.52 2600 38.78 176.27 103.69 49.0 5.0
