Product Description
★lnsuation:Class B
★Type of protection:lP42
★Mode of operation:S1
★Certification:UL/CUL/CE/CCC
★Operation Temperature:-20--70℃
★Material:Pa66
★Available Features:
·Tachilable Out put
·Autorestart
·Slow startup
·Pulse wIDTH Modulation
·control input 0--10VDC
★EMC:Interference emission acc.to EN 61000-6-3
★lnterference immunily acc.to EN 61000-6-2
Product conforming to standard: EN 60950-1
●SPECIFICATIONS
| Model | Bearing System | Voltage v | Voltage Range | Current A | Power W | Speed RPM | Noise DBA | Air Flow | Static Pressure | Weight G | ||
| M³/H | CFM | Pa | mmH₂O | |||||||||
| TD1606224HB-K1 | Ball | 24VDC | 20-28 | 4.8 | 115 | 1800 | 63.6 | 602 | 354 | 673 | 68.4 | 2234 |
| TD1606248HB-K1 | Ball | 48VDC | 24-57 | 2,4 | 115 | 1800 | 63.6 | 602 | 354 | 673 | 68.4 | 2234 |
| TD160603HB-K1 | Ball | 310VDC | 120-370 | 0.37 | 115 | 1800 | 63.6 | 602 | 354 | 673 | 68.4 | 2234 |
