TE146190-K1

Outline:

Classification:

Blower;DC /EC Blower


Product Description




★lnsuation:Class B
★Type of protection:lP42
★Mode of operation:S1
★Certification:UL/CUL/CE/CCC
★Operation Temperature:-20--70℃
★Material:Sheet steel \Aluminum\Pa66
★Available Features:
·Tachilable Out put
·Autorestart
·Slow startup
·Pulse wIDTH Modulation
·control input 0--10VDC
★EMC:Interference emission acc.to EN 61000-6-3
★lnterference immunily acc.to EN 61000-6-2
★Product conforming to standard: EN 60950-1

●SPECIFICATIONS


Model Bearing System Voltage v Voltage Range Current A Power W Speed RPM Noise DBA Air Flow Static Pressure Weight G
M³/H CFM Pa mmHO
TE14619001HB-K1 Ball 110V AC 85—130 1.72 155 1600 67 1205 708 533 54 2925.5
TE14619002HB-K1 Ball 220VAC 85—265 0.97 159 1600 67 1205 708 533 54 2925.5
